Glycol Dehydrator

Removes water vapor from gas streams to prevent the formation of hydrates and corrosion in pipelines.

Facility with JT setup

A JT (Joule-Thomson) plant is a system that uses a drop in gas pressure, to create a cooling effect. This process removes heavy hydrocarbons out of the gas in order to meet pipeline specs.

Caterpillar 3606 Ariel JGK

2500 HP compressor used in a gas injection project.

Typical Upstream Facility

Upstream facilities are required to manage pressure safely and prepare oil and gas production for transportation.

Tank Battery with VRT

This tank battery is equipped with vapor recovery towers (VRT) used to recover flash gas at near atmospheric pressure. The VRT provides a controlled closed loop system for safer operations, reduced emissions, and greater recovery.

Wellhead Control

Each wellhead is equipped with a fail-safe actuated valve. In normal operation it is held open with pneumatic pressure. The safety system will automatically relieve the pressure, closing the valve and containing the well, if it senses an upset.

Typical Tank Battery

Storage for produced oil and water.

HP/LP Separator Skid

Skid mounted separators are compact, reduce hookup time and cost.

Indirect Line Heater

A line heater equipped with a choke is used to reduce the well-stream pressure to a manageable pressure while counteracting the JT effect using a heated water bath.

Lease Master Meter

An orifice meter classified as a Lease Master Meter is located at the end of the gas process flow. It is intended to measure all gas leaving a lease or facility and is used for allocation and can be used as a check meter.

Production Flare

Production upsets and low pressure flash gas that cannot be economically compressed and sold is sent to a flare for combustion.

Typical Tank Battery

Inland Waters Riser Platform

Platform with a pig launcher and receiver.

Typical Tank Battery

Orifice Meter Run

Barge Rig

State Waters LA

Pipeline Boring Rig

This boring machine is setup on a barge for boring a pipeline in inland waters. This method is used when surface conditions restrict access.

Inland Water Pipeline Fabrication

Welding line assembled on barges for water installation.

Inland Water Pipeline Installation

This installation method uses floats to float the pipe from the welding line into position. This reduces the need to move the welding line.

Inland Water Pipeline Installation

Once the pipe is fabricated and floated into position, it is lowered down and the floats are removed. The pipe is then buried per the project specifications.

Board Road

Interlocking mats used to construct roads and pads are often used in the gulf coast where soil conditions are not stable enough to support the rig traffic.
